以下是:黑龙江省佳木斯市供应宝武硅钢片B35A300、B35A360、B35A440、B35A550、B35AH300、B35AR300B35AY-1的产品参数
| 产品参数 |
|---|
| 产品价格 | 2/吨 |
|---|
| 发货期限 | 3天内 |
|---|
| 供货总量 | 50000 |
|---|
| 运费说明 | 电议 |
|---|
| 小起订 | 1 |
|---|
| 质量等级 | 精品 |
|---|
| 是否厂家 | 是 |
|---|
| 产品材质 | 冷轧 |
|---|
| 产品品牌 | 宝武日本进口 |
|---|
| 产品规格 | 0.08-0.65 |
|---|
| 发货城市 | 上海武汉 |
|---|
| 产品产地 | 上海武汉 |
|---|
| 加工定制 | 粗加工 |
|---|
| 产品型号 | 多种 |
|---|
| 可售卖地 | 全国 |
|---|
| 质保时间 | 一年 |
|---|
| 适用领域 | 电器马达电机变压器磁感器互感器稳压器继电器电磁开关新能源电机电动汽车变压器军工电机发电机组航天造船汽车等 |
|---|
| 是否进口 | 否 |
|---|
| 品名 | 电工钢 冷轧无取向电工钢 冷轧取向电工钢卷冷轧取向硅钢 取向电工钢冷轧无取向硅钢冷轧无取向硅钢 |
|---|
| 规格 | 0.08 0.1 0.05 0.18 0.2 0.23 0.27 0.3 0.35 0.5 0.65 1.0mm |
|---|
| 包装 | 原厂精包装 |
|---|
| 用途 | 电器马达电机变压器磁感器互感器稳压器继电器电磁开关新能源电机电动汽车变压器军工电机发电机组航天造船汽车等 |
|---|
| 范围 | 供应宝武硅钢片B35A300、B35A360、B35A440、B35A550、B35AH300、B35AR300B35AY-1供应范围覆盖黑龙江省、哈尔滨市、齐齐哈尔市、鹤岗市、大庆市、佳木斯市、牡丹江市、黑河市、绥化市、大兴安岭市 前进县、东风县、郊县、桦南县、桦川县、汤原县、抚远市、同江市、富锦市等区域。 |
|---|
想知道供应宝武硅钢片B35A300、B35A360、B35A440、B35A550、B35AH300、B35AR300B35AY-1产品有多棒？看视频就够了，它比千言万语都更有说服力！
以下是:黑龙江佳木斯供应宝武硅钢片B35A300、B35A360、B35A440、B35A550、B35AH300、B35AR300B35AY-1的图文介绍
鹿程国际贸易(佳木斯市分公司)的优势 1.常备 冲压用钢库存大，公司常备库存万余吨， 2.生产周期时间短。对于客户要求的特殊材质、规格均能在规定的时间内准时交货，为您的工程和生产提供充足的货源保证。 3.价格优惠，厂家直销，决定了我们的价格低于市场。 4.加工配送 在短的时间，配送到达货物，使用现场。 由于 冲压用钢市场价格波动很大，如需报价请来电咨，欢迎惠顾!
电工钢硅钢片应力退火电工钢在剪切、黑龙江佳木斯同城冲片和弯曲加工等机械变形作用下，电磁性能将发生劣化。为此进行应力退火，可以使电工钢的电磁性能恢复至原来水平。应力退火的条件和工艺将根据加工程度、黑龙江佳木斯同城退火炉况等有明显不同，用户务必注意如下几点：(1) 加热与冷却速度电磁性能一般不受加热和冷却速度的影响，但用户需确保材料不变形。(2)退火温度与保温时间取向电工钢退火温度在780-820℃之间较为适宜，为确保退火效果，退火材料应均热的保持，保温时间应根据铁芯形状、黑龙江佳木斯同城装炉量等进行调整。(3)防止渗碳与氧化由于渗碳及氧化会使电磁性能劣化，用户应充分注意炉内气体，并确保炉内气体的露点在较低状态。另外，为防止在退火中发生渗碳，应该在退火前，将铁芯加工过程中润滑油脂等有机化合物干净。同时，为确保退火效果，建议与炉内高温接触部分尽量采用低碳含量材料。有害物质限定承诺 宝钢的取向电工钢产品符合RoHS、黑龙江佳木斯同城REACH有害物质限定要求。
电工钢硅钢片Electrical steel, also known as silicon steel sheet, is an indispensable metal material in the power, electronics, and military industries, and is also the largest functional material in production. It is mainly used as the iron core for various motors, generators, and transformers. Specific total loss (iron loss) is the total power consumed per unit mass of material when the magnetic polarization waveform remains sinusoidal, with a specific peak and frequency. The specific total loss is represented by the symbol P (Jm/f), in W/kg. Example: P1.5/50 represents the specific total loss at a maximum magnetic polarization intensity of 1.5T and a frequency of 50Hz. 3.2 Magnetic Polarization Q/BQB 480-20212 Magnetic polarization intensity refers to the peak magnetic polarization intensity of a specific magnetic field intensity when a sample is subjected to alternating magnetization. Its symbol is J (H), and the unit is T (Tesla). Example: J5000 represents the peak magnetic polarization intensity corresponding to a magnetic field intensity peak of 5000A/m. The material grades in this document are classified based on the nominal maximum specific total loss P1.5/50 (W/kg) at a magnetic polarization strength of 1.5T and a frequency of 50Hz, as well as the nominal thickness of the material. They are further divided into three categories based on product characteristics: ordinary type, stress relief annealing type, and high-efficiency type. Example 1: B35A210 represents a common non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific total loss value P1.5/50 is 2.10W/kg； Example 2: B35AR300 represents a stress relieved annealed non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific total loss value P1.5/50 is 3.00W/kg； Example 3: B35AH230 represents an efficient non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific loss value P1.5/50 is 2.30W/kg. Example 4: 35WW210 represents a normal type WW non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific loss value P1.5/50 is 2.10W/kg. Example 5: 35WH230 represents an efficient WH non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific loss value P1.5/50 is 2.30W/kg. The classification and code of insulation coatings shall comply with the provisions of Table 2. Table 2 Classification and Code of Insulation Coatings Type Code Characteristics of Insulation Coatings Semi organic Thin Coating A Improves Punching Performance and Has Good Weldability Semi organic Thick Coating H has Good Punching Performance and High Interlayer Resistance Semi organic Chromium Free Thin Coating K does not contain chromium and has good weldability Semi organic Chromium Free Thick Coating M does not contain chromium and has good insulation performance Semi organic Chromium Free Extreme Thick Coating J does not contain chromium and has excellent insulation performance Semi organic Chromium Free Ultra Thick Coating L does not contain chromium and has extremely high insulation performance Self adhesive Coating
电工钢硅钢片硅钢是一种硅铁合金。用硅钢轧制的片材是电工领域中应用广的软磁材料，因而硅钢片又称电工钢片。硅钢片广泛用于电动机、发电机、变压器、扼流圈、电磁机构、继电器及测量仪表中电机工业大量使用厚度为0.35～0.50mm的硅钢片,用于：中型旋转机，压缩电机，通用马达，小型精密电机，电动汽车，压缩机，通用电机，电源变压器，精密变压器，节能电机，焊机变压器，稳压器，磁性密封器，加速器用电磁铁，汽车电机等；在电信高频技术中常用0.05~0.20mm的薄带钢片,以便更有效地降低涡流损耗。热轧硅钢片厚度为0.35～0.50mm，密度为7.55～7.70g/cm3,多用于大、中、小型交、直流电动机；冷轧无取向硅钢片厚度为0.35～0.50mm，密度为7.65～7.75g/cm3，多用于大型交流发电机、电动机，大、中、小型交、直流电动机；冷轧取向硅钢片厚度为0.23mm 0.27mm 0.3mm 0.35mm，密度为7.65g/cm3,多用于电力变压器、油浸式变压器，干式变压器，电抗器、磁放大器等；冷轧取向薄带厚度为0.05～0.20mm，多用于无线电高频变压器。
供应宝武硅钢片B35A300、B35A360、B35A440、B35A550、B35AH300、B35AR300B35AY-1,鹿程国际贸易(佳木斯市分公司)专业从事供应宝武硅钢片B35A300、B35A360、B35A440、B35A550、B35AH300、B35AR300B35AY-1,联系人:鹿丙伟,供应服务范围覆盖:黑龙江省 哈尔滨市、齐齐哈尔市、鹤岗市、大庆市、佳木斯市、牡丹江市、黑河市、绥化市、大兴安岭市 前进县、东风县、郊县、桦南县、桦川县、汤原县、抚远市、同江市、富锦市,以下是供应宝武硅钢片B35A300、B35A360、B35A440、B35A550、B35AH300、B35AR300B35AY-1的详细页面。
